TAKISAWA TMX-SERIES
The Takisawa TMX Series Multi-Axis CNC Machines are cutting-edge turning machines designed for productivity and precision. Equipped with original Soft TiwaP-1, these multi-axis CNC machining centers excel in creating complex parts with fewer setups, offering unmatched accuracy, superior surface finish, and extended tool life. Ideal for iterative design and product development, these CNC machines boost production efficiency, reduce costs, and deliver high-quality prototypes and parts, making them a versatile choice for modern manufacturing.
Request A Quote
Specifications
Specifications
| Specification |
Detail |
| Max. Turning Length |
59.06" |
| Maximum Turning Diameter |
19.69" |
| Bar Capacity |
3.15" |
| Chuck Size |
10" |
| X-Axis Travel (Tool Spindle) |
23.82" |
| Y-Axis Travel (Tool Spindle) |
10.24" |
| Z-Axis Travel (Tool Spindle) |
59.06" |
| Number of Turrets |
12 |
| Type of Turret |
Tool Spindle with ATC |
| ATC Storage Capacity |
40 (opt. 80, 120) |
| Spindle Speed |
12000 |
| Max. Tool Diameter |
3.54" (4.92") |
| Max. Tool Length |
15.75" |
| Specification |
Detail |
| Max. Turning Length |
22.24" |
| Maximum Turning Diameter |
19.69" |
| Bar Capacity |
2.01" |
| X-Axis Travel |
24.8" |
| Y-Axis Travel |
9.06" |
| Z-Axis Travel |
27.17" |
| Number of Turrets |
1 |
| Type of Turret |
ATC |
| Number of Attachable Tools |
1 |
| Spindle Speed |
12000 |
| ATC Time (TtoT) |
2 |
| Max. Tool Diameter |
4.92" |
| Max. Tool Length |
11.81" |
| Specification |
Detail |
| Max. Turning Length |
22.24" |
| Maximum Turning Diameter |
19.69" |
| Bar Capacity |
L:65 2.56", R:51 2.01" |
| X-Axis Travel |
24.8" |
| Y-Axis Travel |
9.06" |
| Z-Axis Travel |
27.17" |
| Number of Turrets |
1 |
| Type of Turret |
ATC |
| Number of Attachable Tools |
1 |
| Spindle Speed |
12000 |
| ATC Time (TtoT) |
2 |
| Max. Tool Diameter |
4.92" |
| Max. Tool Length |
11.81" |
Features
Features
The Takisawa TMX Series is a productive, multi-tasking machine with original Soft TiwaP-1 installed.
Takisawa has recently released the new high speed, multitasking machine the TMX-4000ST. This highly-precision machine has an extended work area with a large axis travel; X-axis 605 mm, Y-axis 260 mm, and Z-axis 1500 mm. Highly accurate machining, milling and end face drilling, is possible by one chucking with the C-axis (turning spindle) fixed.
