TAKISAWA TMT-SERIES
The Takisawa TMT Series CNC Machines are innovative multi-axis CNC machining centers designed for efficiency and precision. With an optional twin turret arrangement, they enable simultaneous machining on the same workpiece, dramatically reducing cycle times. These versatile turning machines excel in creating complex parts with superior surface finish and accuracy, enhancing tool life while boosting production efficiency. Ideal for product development, prototypes, and cost-effective manufacturing, the TMT Series redefines multi-axis CNC machining excellence.
Request A Quote
Specifications
Specifications
| Specification |
Detail |
| Maximum Swing |
32.28" |
| Maximum Turning Dia. (Tool Spindle) |
24.80" |
| Maximum Turning Dia. (Lower Turret) |
13.78" |
| Maximum Turning Length |
78.47" |
| Bar Capacity |
3.54" |
| X1-Axis Travel (Tool Spindle) |
32.28" |
| Y-Axis Travel (Tool Spindle) |
16.93" |
| Z1-Axis Travel (Tool Spindle) |
78.74" |
| A-Axis Travel (Right Spindle Stock) |
76.38" |
| X2-Axis Travel (Lower Turret) |
9.84" |
| Z2-Axis Travel (Lower Turret) |
76.38" |
| Spindle Speed |
3200 |
| Tool Spindle Speed |
12000 |
| Number of Lower Turret Tools |
4+4 |
| Tool Storage |
30 (60, 90 optional) |
| Specification |
Detail |
| Maximum Swing |
32.28" |
| Maximum Turning Dia. (Tool Spindle) |
24.80" |
| Maximum Turning Dia. (Lower Turret) |
- |
| Maximum Turning Length |
78.47" |
| Bar Capacity |
3.54" |
| X1-Axis Travel (Tool Spindle) |
32.28" |
| Y-Axis Travel (Tool Spindle) |
16.93" |
| Z1-Axis Travel (Tool Spindle) |
78.74" |
| A-Axis Travel (Right Spindle Stock) |
76.74" |
| X2-Axis Travel (Lower Turret) |
- |
| Z2-Axis Travel (Lower Turret) |
- |
| Spindle Speed |
3200 |
| Tool Spindle Speed |
12000 |
| Number of Lower Turret Tools |
4+4 |
| Tool Storage |
30 (60, 90 optional) |
| Specification |
Detail |
| Maximum Swing |
32.28" |
| Maximum Turning Dia. (Tool Spindle) |
24.80" |
| Maximum Turning Dia. (Lower Turret) |
13.78" |
| Maximum Turning Length |
78.47" |
| Bar Capacity |
3.54" |
| X1-Axis Travel (Tool Spindle) |
32.28" |
| Y-Axis Travel (Tool Spindle) |
16.93" |
| Z1-Axis Travel (Tool Spindle) |
78.74" |
| A-Axis Travel (Right Spindle Stock) |
- |
| X2-Axis Travel (Lower Turret) |
- |
| Z2-Axis Travel (Lower Turret) |
- |
| Spindle Speed |
3200 |
| Tool Spindle Speed |
12000 |
| Number of Lower Turret Tools |
4+4 |
| Tool Storage |
30 (60, 90 optional) |
| Specification |
Detail |
| Maximum Swing |
32.28" |
| Maximum Turning Dia. (Tool Spindle) |
24.80" |
| Maximum Turning Dia. (Lower Turret) |
- |
| Maximum Turning Length |
78.47" |
| Bar Capacity |
3.54" |
| X1-Axis Travel (Tool Spindle) |
32.28" |
| Y-Axis Travel (Tool Spindle) |
16.93" |
| Z1-Axis Travel (Tool Spindle) |
78.74" |
| A-Axis Travel (Right Spindle Stock) |
- |
| X2-Axis Travel (Lower Turret) |
- |
| Z2-Axis Travel (Lower Turret) |
- |
| Spindle Speed |
3200 |
| Tool Spindle Speed |
12000 |
| Number of Lower Turret Tools |
4+4 |
| Tool Storage |
30 (60, 90 optional) |
Features
Features
The Takisawa TMT Series is an optional twin turret machine whose arrangement offers simultaneous machining using both turrets on the workpiece at the same time; reducing cycle times and maximizing this machine’s capability.
