NIDEC MAF-C SERIES
NIDEC MAF-C SERIES
NIDEC MAF-C SERIES
NIDEC MAF-C SERIES
NIDEC MAF-C SERIES
NIDEC MAF-C SERIES
NIDEC MAF-C SERIES

NIDEC MAF-C SERIES

The Nidec MAF-C Series has accuracy compensation mechanisms that represent a different approach to the status quo which we have found due to our extensive analysis technologies. The MAF-C is a world-leading machine that has improved accuracy, cutting ability and rigidity; enabling even deeper cuts

Request A Quote

Specifications

Specifications

Specification Detail
X-Axis Travel 196.9" (opt. 78.7)
Y-Axis Travel 118.1 (opt. 157.5", 196.9")
Z-Axis Travel (Column in/out) 49.2
W-Axis Travel (Spindle in/out) 39.4"
Milling Spindle Diameter Φ7.9"
Boring Spindle Diameter Φ5.9"
Spindle RPM 6~2,500
Spindle Taper No. 50
Spindle Horsepower 74/101/114
Machine Weight 77,200 lbs

Specification Detail
X-Axis Travel 196.9" (opt. 78.7)
Y-Axis Travel 118.1 (opt. 157.5", 196.9")
Z-Axis Travel (Column in/out) 49.2
W-Axis Travel (Spindle in/out) 39.4"
Milling Spindle Diameter Φ9.4"
Boring Spindle Diameter Φ7.1"
Spindle RPM 6~2,500
Spindle Taper No. 50
Spindle Horsepower 74/101/114
Machine Weight 77,200 lbs
