NIDEC MVR HX Series
The Nidec MVR-Hx Series Large Bridge Mill is a state-of-the-art CNC machine designed for precision and versatility. This large CNC machining center excels in large part machining with its double-column, five-face milling capability. Ideal for a wide range of CNC machining tasks, the MVR-Hx ensures high-precision results across varying speeds, while its thermo-stabilizer column maintains accuracy, making it a premier choice for large CNC machines.
Request A Quote
Specifications
Specifications
| Specification |
Detail |
| Distance Between Columns |
80.7" |
| Distance from Table to Spindle Nose |
65.0" / 79.1" |
| Table Width |
59.1" |
| Table Length |
118.1" - 315" |
| Table Longitudinal (X-Axis) |
126.0" - 322.8" |
| Saddle Crosswise (Y-Axis) |
98.4" / 106.3" |
| Ram Vertical (Z-Axis) |
31.5" / 39.4" |
| Crossrail Vertical (W-Axis) |
39.4" / 43.3" |
| Ram Size |
13.8" x 13.8" |
| Spindle Speed |
8,000 RPM (other options avail.) |
| Spindle HP |
30/40 HP |
| Number of Tools |
60 (options up to 180) |
| Rapid Traverse X-Axis Travel |
1,181 imp (other options avail.) |
| Rapid Traverse Y-Axis Travel |
1,378 ipm |
| Rapid Traverse Z-Axis Travel |
787 ipm |
| Rapid Traverse W-Axis Travel |
197 ipm |
| Specification |
Detail |
| Distance Between Columns |
100.4" |
| Distance from Table to Spindle Nose |
65.0" / 79.1" |
| Table Width |
78.7" |
| Table Length |
118.1" - 393.7" |
| Table Longitudinal (X-Axis) |
126.0" - 401.6" |
| Saddle Crosswise (Y-Axis) |
118.1" / 124" |
| Ram Vertical (Z-Axis) |
31.5" / 39.4" |
| Crossrail Vertical (W-Axis) |
39.4" / 43.3" |
| Ram Size |
13.8" x 13.8" |
| Spindle Speed |
8,000 RPM (other options avail.) |
| Spindle HP |
30/40 HP |
| Number of Tools |
60 (options up to 180) |
| Rapid Traverse X-Axis Travel |
1,181 imp (other options avail.) |
| Rapid Traverse Y-Axis Travel |
1,378 ipm |
| Rapid Traverse Z-Axis Travel |
787 ipm |
| Rapid Traverse W-Axis Travel |
197 ipm |
| Specification |
Detail |
| Distance Between Columns |
128" |
| Distance from Table to Spindle Nose |
72.8" / 84.6" |
| Table Width |
98.4" |
| Table Length |
157.5" - 393.7" |
| Table Longitudinal (X-Axis) |
165.4" - 401.6" |
| Saddle Crosswise (Y-Axis) |
137.8" / 153.5" |
| Ram Vertical (Z-Axis) |
31.5" / 39.4" |
| Crossrail Vertical (W-Axis) |
51.2" |
| Ram Size |
13.8" x 13.8" |
| Spindle Speed |
8,000 RPM (other options avail.) |
| Spindle HP |
30/40 HP |
| Number of Tools |
60 (options up to 180) |
| Rapid Traverse X-Axis Travel |
886 rpm (other options avail.) |
| Rapid Traverse Y-Axis Travel |
1,378 ipm |
| Rapid Traverse Z-Axis Travel |
787 ipm |
| Rapid Traverse W-Axis Travel |
197 ipm |
| Specification |
Detail |
| Distance Between Columns |
147.6" |
| Distance from Table to Spindle Nose |
72.8" / 84.6" |
| Table Width |
118.1" |
| Table Length |
157.5" - 393.7" |
| Table Longitudinal (X-Axis) |
165.4" - 401.6" |
| Saddle Crosswise (Y-Axis) |
157.5" / 173.2" |
| Ram Vertical (Z-Axis) |
31.5" / 39.4" |
| Crossrail Vertical (W-Axis) |
51.2" |
| Ram Size |
13.8" x 13.8" |
| Spindle Speed |
8,000 RPM (other options avail.) |
| Spindle HP |
30/40 HP |
| Number of Tools |
60 (options up to 180) |
| Rapid Traverse X-Axis Travel |
886 rpm (other options avail.) |
| Rapid Traverse Y-Axis Travel |
1,102 ipm |
| Rapid Traverse Z-Axis Travel |
787 ipm |
| Rapid Traverse W-Axis Travel |
197 ipm |
| Specification |
Detail |
| Distance Between Columns |
167.3" |
| Distance from Table to Spindle Nose |
84.6" |
| Table Width |
137.8" |
| Table Length |
236.2" - 393.7" |
| Table Longitudinal (X-Axis) |
244.1" - 401.6" |
| Saddle Crosswise (Y-Axis) |
177.2" / 192.9" |
| Ram Vertical (Z-Axis) |
31.5" / 39.4" |
| Crossrail Vertical (W-Axis) |
51.2" |
| Ram Size |
13.8" x 13.8" |
| Spindle Speed |
8,000 RPM (other options avail.) |
| Spindle HP |
30/40 HP |
| Number of Tools |
60 (options up to 180) |
| Rapid Traverse X-Axis Travel |
787 imp (other options avail.) |
| Rapid Traverse Y-Axis Travel |
886 ipm |
| Rapid Traverse Z-Axis Travel |
787 ipm |
| Rapid Traverse W-Axis Travel |
197 ipm |
Features
Features
The MVR-Hx series, a cutting-edge double-column, five-face milling machine offers precision and versatility for a wide range of machining tasks. The MVR-Hx series ensures high-precision machining across various speed ranges, while its thermo-stabilizer column maintains geometric accuracy even in fluctuating temperatures. Combined with their team of U.S. based, factory-trained technicians, Nidec Machine Tool America LLC has the machines and support for your large part machining needs.
